Precision sheet metal technology workshop
Equipment Introduction
Our company has the following main machines:
● Japanese AMADA2510NT CNC punch machine;
● Japanese AMADALCG 3015 3500W laser cutting machine;
● HSG laser high power cutting machine HS-G4020A;
● Imported AMADA bending machines, including one withthe maximum tonnage of 100 tones ;
● Squeeze riveters, many Panasonic welding machines andother auxiliary equipments.
1CNC Turret Punch Machine
| Max Processing Range | 5000mm*1250mm |
| Max Processing Thickness Stainless Steel | 1.5mm |
| Max Processing Thickness of Carbon Steel | 3.0mm |
| Max Processing Thickness of Aluminium | 5.0mm |
| Precision | +0.1mm |
2AMADA 3015 3500 Laser Cutting Machine
| Max Cutting Size | 3000mm*1500mm |
| Max Cutting Thickness of Carbon Steel | 20mm |
| Max Cutting Thickness of Stainless Steel | 10mm |
| Max Cutting Thickness of Aluminium | 8mm |
| Precision | +0.1mm |
3HSG Laser High Power Cutting Machine
| Max Cutting size | 4000mm*2000mm |
| Axis Positioning Accuracy | 0.03mm/m |
| X/Y Axis Repeated Positioning Accuracy | 士0.03mm |
| Max Speed | 100m/min |
| Max Acceleration | 1.0G |
4AMADA Bending Machine
| Max bending length | 3200mm |
| Max bending tonnage | 100t |
| Precision | 土0.1mm |
5Squeeze Riveter, Bench Drill, Tapping Machine and Stamping Machine
6Many TIG/MAG welding machines and welding tables
Many TIG/MAG welding machines and welding tables, which can be used to weldstainless steels.carbon steels and so on.
